PN-2 Zinc Plating Chemicals Water Soluble Sealant Chrome Free Sealant
1. Properties
1. A kind of environmentally-friendly sealant which does not contain hexavalent chromium.
2. Can form an organic protective film with good hardness and gloss.
3. It can be used on other decorative coatings such as copper and copper alloys, nickel layers, gun black, phosphating layers, chromium layers, etc
4. Easy to operate. Suitable for the sealing after treating a variety of zinc passivation layers. Can prolong the lifetime of passivation layers.
2. Process Flow
Zinc plating → Wash → Treat with diluted nitric acid → Wash → Passivate → Wash with recycled water → Seal with PN-2 → Dry (60~80°C)
3. Process Parameters
PN-2 Sealant: 200-400ml/L
Temperature: room temperature
Time: 30-80 seconds
pH: 8-9
Drying temperature: 60~80°C (the higher the temperature, the shorter the sealing time, but no more than 120°C)
