1. Properties
1. The cathode current efficiency is 20~60%, high deposition speed, is generally the traditional hard chrome of the 2~3 times.
2. The hardness of the coating can be stabilized to 950Hv above.
3. The number of microcracks is greater than 400bar/cm.
4. The coating is fine and bright, and the plating ability is good.
5. Wide current range (30~80A/dm2), a wide range of process conditions, easy to maintain.
6. Widely used in construction machinery, automobiles, motorcycles and other fields of electroplating hard chromium.
2. Bath composition & Operation condition
|
Operation range |
CrO3 |
180~280g/L |
H2SO4 |
3~4.5g/L |
FI-5680A |
5~10ml/L |
FI-5680B | 35~10ml/L |
Temperature |
52~62℃ |
Cathode current density(Dk) |
30~70A/dm2 |
Anode |
Lead-tin alloy (8~20% tin content) |
