FF-5131 Cyanide-free Copper Plating Chemicals for Fast Deposition Stable Process and Uniform Coating
-
Highlight
Fast Deposition Copper Plating Chemicals
,Stable Process Copper Plating Chemicals
,Uniform Coating Cyanide-free Copper-Zinc Alloy Process
-
TypeBrightener
-
UseCopper Zinc Alloy Plating
-
CharacteristicCyanide-free
-
FeatureFast Deposition, Stable Process
-
Place of OriginCHINA
-
Brand NameFENGFAN
-
Model NumberFF-5131
FF-5131 Cyanide-free Copper Plating Chemicals for Fast Deposition Stable Process and Uniform Coating
FF-5131 Cyanide-Free Copper-Zinc Alloy Process / Copper Plating Chemicals
Product Features
- This process does not contain sodium (potassium) cyanide, lead, cadmium or other heavy metals
- Produces uniform, stable coatings with consistent brass appearance
- Excellent alignment suitable for both roll plating and rack plating
- Can be used for both surface coloring and thick brass plating (above 10μm)
- Primarily used in decoration, jewelry, handicrafts, and industrial applications
- Environmentally friendly alternative to precious metal cyanide plating
- 30% lower production and operating costs compared to sodium cyanide systems
Process Flow
Copper plating → Recycling → Rinsing → Activation (5~10% Sulphuric acid) → Rinsing → Plating of full bright nickel → Recycling → Rinsing → Activation (5% sulphuric acid) → Rinsing → Pure water rinsing → Electroplating cyanide-free copper-zinc alloy Gold → water washing → passivation → water washing → pure water washing → drying → spraying and baking.
Bath Composition and Operating Conditions
| Item | Range | Optimal |
|---|---|---|
| FF-5131M | 800～940ml/L | 900ml/L |
| FF-5131A | Use for supplement | ---- |
| FF-5131B | 50～60ml/L | 60ml/L |
| Temperature | 35～45℃ | 40℃ |
| Time | 3～30min | 5min |
| pH | 10～11.8 | 10.8 |
| Dk | 0.3～1.0A/dm² | |
| Anod | Brass plate (copper : zinc ratio 70:30) | |
| Stirring method | Cathodic movement / plating flow | |
| Cycle filtering | Continuous filtration, the capacity of cotton core is 2~3 times per hour | |
