Alkaline Etching Additive AE-101
1. Brief Introduction
AE-101 is mainly used as alkaline etching auxiliary, which can replace the traditional acid etching, improve efficiency and reduce acid emission.
2. Characteristics
² Improvement of environmental protection performance: replace traditional acid etching, reduce acid emission, and improve the working environment;
² Polishing efficiency is good: polishing back than traditional acid polishing high
² Efficiency: alkali etching than traditional acid polishing has significant efficiency gains
3. Management
Ø AE-101 should be kept sealed for 6 months.
Ø Avoid direct sunlight or high heat.
Ø AE-101 does not need to be stirred before use.
Ø Do not mix leftover alkaline etching aids with expired products.
4. Technical Control
(Taking a customer as an example)
Chemical |
Make-up(Temperature 81-83℃) |
Replenish(mL/pcs) |
45%NaOH |
2~9 L |
260~320 /480 |
AE-101 |
2~3 L |
140~200/480 |
Water |
470~472L |
5000~9000/480 |
Note: The above data is for reference only, as the situation of each customer is different.
