Non Cyanide Alkaline Copper Plating Chemical Auxiliary Agent FF-5100
-
Highlight
Non Cyanide Copper Plating Chemical
,Alkaline Copper Plating Agent
,Copper Plating Auxiliary Agent FF-5100
-
TypeBrightener
-
ItemChemical Auxiliary Agent
-
UseCopper Plating
-
FeatureFast Deposition, Stable Process
-
CharacteristicCyanide-free
-
Place of OriginCHINA
-
Brand NameFENGFAN
-
Model NumberFF-5100
-
Minimum Order QuantityNegotiable
-
PriceNegotiable
-
Packaging DetailsStandard export packaging
-
Delivery Time15-25 work days
-
Payment TermsL/C,D/A,D/P,T/T,Western Union,MoneyGram
-
Supply Ability200000pcs/day
Non Cyanide Alkaline Copper Plating Chemical Auxiliary Agent FF-5100
FF-5100 Alkaline Copper Plating (cyanide-free) ; Electroplating additive
Product Details
Non-cyanide, suitable for direct copper plating for iron and steel substrate, also suitable for aluminum alloy and zinc alloy.
Has excellent dispersion and coverage, coating fine, smooth, soft and a certain brightness.
Single component supplement, simple operation , wide temperature range, can be at 40 ~ 50 ℃.
Coating surface is not hydrophobic, without removing the film, can be directly plated with nickel or other metals.
Process Specification Conditions
| FF-5100M | 400~600ml/L |
| pH | 8.8~9.5 |
| Anode | Electrolytic copper |
| Temp. | 40~50℃ |
| Current density | 1.0~3.0 A/dm2 |
| SK:SA | 1:1~2 |
| Filtering | continuous |
| Cathode move (or air agitation) | Required |
Process Flow:
Pre-treatment → washing → washing → acide activation → washing →washing → copper plating(FF-5100) → Washing → Post-processing
